Brand: elites
Origin: China
Delivery time:2weeks-4 weeks
Supply capacity:Mass production
GA05 5G Vehicle Terminal supports dual-band GNSS positioning, IMU inertial navigation, and JT808 protocol. With built-in TF/SIM slots, it connects to major carriers and is compatible with 4G/5G networks. Features include centimeter-level RTK accuracy, CAN/GPIO interfaces, remote relay control, and dual-antenna heading/tilt measurement. Ideal for intelligent transport, logistics, and autonomous driving applications.
Product Parameters
|
RTK Positional accuracy |
2cm+1ppm |
|
|
Velocity measurement accuracy |
0.05m/s |
|
|
UpdateRate |
1-10HZ(Default 1HZ) |
|
|
Capture time |
Cold Start |
<4s |
|
Hot start |
<1s |
|
|
Channel |
Acquisition channel |
96个 |
|
Tracking channel |
60个 |
|
|
Sensitivity |
Tracking sensitivity |
-163dBm |
|
Acquisition sensitivity |
-163dBm |
|
|
Baud rate |
115200(Default) |
|
|
Power interface |
DC 9-36V |
|
|
Working current |
<=200mA |
|
|
Working temperature |
-20℃~65℃ |
|
|
Storage temperature |
-30℃-80℃ |
|
|
Weight |
About 80g |
|
|
Operating humidity |
10%~85%RH，Unquestionable knot |
|
|
SIM Card |
Nano SIM |
|
|
I/O |
I/O |
|
|
IECEx |
Customers for explosion-proof certification |
|
